Additional information
| Product variants | 3 x 400 V / 50 Hz – Cleanable Filter, 3 x 460 V / 60 Hz – Cleanable Filter, 3 x 600 V / 60 Hz – Cleanable Filter |
|---|
| Product variants | 3 x 400 V / 50 Hz – Cleanable Filter, 3 x 460 V / 60 Hz – Cleanable Filter, 3 x 600 V / 60 Hz – Cleanable Filter |
|---|
| Filter stages | 1 |
| Filter method | Cleanable filter |
| Filter surface | 6.7 m² |
| Type of filter | Filter cartridge |
| Filter material | KemTex® ePTFE membrane |
| Filter efficiency | > 99.9 % |
| Dust classification | M |
| Max. extraction capacity | 280 m³/h |
| Extraction performance at 18000 Pa | 215 m³/h |
| Max. fan performance | 280 m³/h |
| Maximum vacuum | 32000 Pa |
| Dimensions (w x t x h) | 692 x 1018 x 878 mm |
| Weight | 83 kg |
| Motor power | 3.8 kW |
| Power supply | 3 x 400 V / 50 Hz |
| Rated current | 8.1 A |
| Noise level | 73 dB(A) |
| IFA-Certification | Certification submitted |
| Fan type | Slide channel blower |
| Compressed air supply | 6 – 8 bar |
| Hose connection | Ø 2 x D = 45 / 63 mm |
| Air outlet | 63 mm |
